USB Logic Analyzer, 16 Channels, Up to 400MHz Sampling Rate, 16G Depth for Comprehensive Data Analysis

Product description Features:* 16-channel dual-mode support: ① Stream mode can capture and transmit data in real time to achieve long-term sampling; ② Buffer mode can temporarily capture and store data to achieve high sampling rate.* 2.0 interface, sampling depth up to 16G in stream mode.* Support adjustable threshold and shield line for better and clearer waveform.* 256Mbits onboard SDRAM memory, support for multiple buffer modes.* For WinXP-for Win10, for macOS and for Linux, supports nearly 100 protocol decoders, and open source on.Specifications：Part Name: Logic AnalyzerMaterial: MetalColor: BlackNumber of Channels: 16USB Transfer Rate: USB2.0 (480bps)Sampling Rate in Buffer Mode: 400MHz @ 4 Channels / 200MHz @ 8 Channels / 100MHz @ 16 ChannelsSampling Rate in Stream Mode: 100MHz @ 3 Channels / 50MHz @ 6 Channels / 25MHz @ 12 Channels / 20MHz @ 16 ChannelsMinimum Sampling Pulse Width: 5nsMaximum Sampling Signal: 100MHzMaximum Sampling Depth: 16G in Stream Mode / 256M in Buffer ModeMaximum Sampling Duration in Stream Mode: 160 seconds @ 100M / 4 hours @ 1M / 19 days @ 10KHardware Memory: 256MbitsThreshold: 0-5V (Step Size 0.1V)Input voltage: -30V~+30VInput impedance: 250KΩ//~13pFState sampling: up to 50MHzSupported operating systems: Win, for Mac OS, for LinuxSize: 3.1*2.9*0.4 inchesPackage contents:1 x logic analyzer4 x shielded wire set1 x USB 2.0 data cable16 x test hooks1 x English manual Manufacturer Contact Information no

• [16 CHANNEL DUAL MODE SUPPORT] This USB Logic Analyzer features dual modes, allowing for real-time data capture in Stream mode or high sampling rates in Buffer mode, making it suitable for various testing scenarios.
• [EXTENSIVE SAMPLING DEPTH] With a 16G sampling depth in Stream mode, you can perform long-term sampling without losing crucial data, perfect for complex signal analysis.
• [ADJUSTABLE THRESHOLD FOR CLEARER WAVEFORMS] The adjustable threshold and shield line help enhance waveform , providing more accurate results during your analysis .
• [256MB ONBOARD SDRAM MEMORY] Equipped with 256Mbits of onboard SDRAM, this analyzer supports Buffer mode, ensuring efficient data storage and management for your testing needs.
• [SYSTEM COMPATIBILITY] Compatible with 10, , and , this device supports nearly 100 protocol decoders and is open-source, catering to diverse user requirements.
